Açıklama
S9M features the typical characteristics of S-shaped force transducers such as high measurement accuracy and an excellent price-to-performance ratio. A special feature that should be emphasized is the robust S9M force transducer’s high precision and its resulting classification with accuracy class 0.02.
Cutting-edge force measurement
S9M offers nominal (rated) forces ranging from 500 N to 50 kN. All measuring bodies, even the one for a nominal (rated) force of 500 N, are made from stainless steel. Force is applied either directly via the two central internal threads or via knuckle eyes that can be ordered as an option. In addition, S9M features welded and therefore hermetically sealed strain gage installation that enables the force transducer to be classified with degree of protection IP68.
Due to its multiple applications in experimental stress analysis, OEM applications or test equipment, the S9M force transducer ideally complementsHBM’s wide range of force transducers. Together with its force transducers for dynamic applications (U10M) and transducers for small nominal (rated) forces (S2), HBM covers the complete range of force transducers for test equipment.
Now even more powerful
Critical elements have been optimized and now the new S9M force transducer replaces its predecessor S9. S9M has been designed to allow continued use of all force application parts used so far. The height and width of the predecessor model have remained unchanged; the S9 force transducer can therefore easily be replaced with its successor S9M.
| Title | Description | Date | Version | Size | Related Documents |
|---|---|---|---|---|---|
| S9M Data Sheet | Data Sheet of the S9M Force Sensor (English) | 212 KB | |||
| S9M Mounting Instructions | Mounting Instructions, Montageanleitung, Notice de montage, Istruzioni per il montaggio (English, Deutsch, Français, Italiano) | 441 KB | |||
| S9M Caractéristiques techniques | Français | 215 KB | |||
| S9M Datenblatt | Datenblatt des Kraftaufnehmers S9M (Deutsch) | 213 KB | |||
| Brochure | Deutsch | 726 KB | |||
| S9M Prospetto dati | Italiano | 161 KB | |||
| S9M Istruzioni per il montaggio | Italiano | 472 KB | |||
| S9M Data Sheet (Japanese) | Japanese Data Sheet of S9M Force Sensor | 291 KB |
CAD Drawings
Key Features
- Direction of force: Tension/ Compression
- Accuracy class: 0.02
- Material: Stainless steel
- IP68 protection (100 h in 1 m water depth)
- Max. operating force: 150%
- Nominal (rated) temperature range: -10°C … +70°
- Nominal (rated) forces: 0.5 k, 1 k, 2 k, 5 k, 10 k, 20 k, 50 k
- Nominal (rated) sensitivity: 2mV/V
- High lateral force stability
- Six-wire circuit
Order Numbers
1-S9M/500N-1
1-S9M/1KN-1
1-S9M/2KN-1
1-S9M/5KN-1
1-S9M/10KN-1
1-S9M/20KN-1
1-S9M/50KN-1
